| NO. | Part Number | Package | DC Spark-over Voltage @100V/s (V) | Maximum Impulse Spark-over Voltage @1000V/µs (V) | Nominal Impulse Discharge Current @8/20µs， ±5times(KA) | Alternating Discharge Current @50Hz,1s(A) | Minimum Insulation Resistance(MΩ) | @VT(V) | CJ_Max(pF) |
| 1 | 2RP075M-8 | SMD,8.0*6.0mm | 75±20% | 600 | 20 | 20 | 1000 | 25 | 1.5 |
| 2 | 2RP090M-8 | SMD,8.0*6.0mm | 90±20% | 600 | 20 | 20 | 1000 | 50 | 1.5 |
| 3 | 2RP150M-8 | SMD,8.0*6.0mm | 150±20% | 700 | 20 | 20 | 1000 | 100 | 1.5 |
| 4 | 2RP230M-8 | SMD,8.0*6.0mm | 230±20% | 700 | 20 | 20 | 1000 | 100 | 1.5 |
| 5 | 2RP250M-8 | SMD,8.0*6.0mm | 250±20% | 800 | 20 | 20 | 1000 | 100 | 1.5 |
| 6 | 2RP300M-8 | SMD,8.0*6.0mm | 300±20% | 900 | 20 | 20 | 1000 | 100 | 1.5 |
| 7 | 2RP350M-8 | SMD,8.0*6.0mm | 350±20% | 900 | 20 | 20 | 1000 | 100 | 1.5 |
| 8 | 2RP400M-8 | SMD,8.0*6.0mm | 400±20% | 1000 | 20 | 20 | 1000 | 100 | 1.5 |
| 9 | 2RP470M-8 | SMD,8.0*6.0mm | 470±20% | 1100 | 20 | 20 | 1000 | 250 | 1.5 |
| 10 | 2RP600M-8 | SMD,8.0*6.0mm | 600±20% | 1300 | 20 | 20 | 1000 | 250 | 1.5 |
| 11 | 2RP800M-8 | SMD,8.0*6.0mm | 800±20% | 1500 | 20 | 20 | 1000 | 250 | 1.5 |
| 12 | 2RP075L-8 | 插件,8.0*6.0mm | 75±20% | 600 | 20 | 20 | 1000 | 25 | 1.5 |
| 13 | 2RP090L-8 | 插件,8.0*6.0mm | 90±20% | 600 | 20 | 20 | 1000 | 50 | 1.5 |
| 14 | 2RP150L-8 | 插件,8.0*6.0mm | 150±20% | 700 | 20 | 20 | 1000 | 100 | 1.5 |
| 15 | 2RP230L-8 | 插件,8.0*6.0mm | 230±20% | 700 | 20 | 20 | 1000 | 100 | 1.5 |
| 16 | 2RP250L-8 | 插件,8.0*6.0mm | 250±20% | 800 | 20 | 20 | 1000 | 100 | 1.5 |
| 17 | 2RP300L-8 | 插件,8.0*6.0mm | 300±20% | 900 | 20 | 20 | 1000 | 100 | 1.5 |
| 18 | 2RP350L-8 | 插件,8.0*6.0mm | 350±20% | 900 | 20 | 20 | 1000 | 100 | 1.5 |
| 19 | 2RP400L-8 | 插件,8.0*6.0mm | 400±20% | 1000 | 20 | 20 | 1000 | 100 | 1.5 |
| 20 | 2RP470L-8 | 插件,8.0*6.0mm | 470±20% | 1100 | 20 | 20 | 1000 | 250 | 1.5 |
| 21 | 2RP600L-8 | 插件,8.0*6.0mm | 600±20% | 1300 | 20 | 20 | 1000 | 250 | 1.5 |
| 22 | 2RP800L-8 | 插件,8.0*6.0mm | 800±20% | 1500 | 20 | 20 | 1000 | 250 | 1.5 |
