| NO. | Part Number | Package | DC Spark-over Voltage @100V/s (V) | Maximum Impulse Spark-over Voltage @1000V/µs (V) | Nominal Impulse Discharge Current @8/20µs， ±5times(KA) | Alternating Discharge Current @50Hz,1s(A) | Minimum Insulation Resistance(MΩ) | @VT(V) | CJ_Max(pF) |
| 1 | 2RK2700L-8 | 插件,8.0*8.0mm | 2700±20% | 4000 | 3 | 3 | 1000 | 1000 | 1.5 |
| 2 | 2RK3000L-8 | 插件,8.0*8.0mm | 3000±20% | 4200 | 3 | 3 | 1000 | 1000 | 1.5 |
| 3 | 2RK3500L-8 | 插件,8.0*8.0mm | 3500±20% | 5000 | 3 | 3 | 1000 | 1000 | 1.5 |
| 4 | 2RK3600L-8 | 插件,8.0*8.0mm | 3600±20% | 5200 | 3 | 3 | 1000 | 1000 | 1.5 |
| 5 | 2RL600L-8 | 插件,8.0*8.0mm | 600±20% | 1800 | 5 | 5 | 1000 | 500 | 1.5 |
| 6 | 2RL1000L-8 | 插件,8.0*8.0mm | 1000±20% | 2200 | 5 | 5 | 1000 | 500 | 1.5 |
| 7 | 2RL1200L-8 | 插件,8.0*8.0mm | 1200±20% | 2200 | 5 | 5 | 1000 | 500 | 1.5 |
| 8 | 2RL1400L-8 | 插件,8.0*8.0mm | 1400±20% | 2200 | 5 | 5 | 1000 | 500 | 1.5 |
| 9 | 2RL1500L-8 | 插件,8.0*8.0mm | 1500±20% | 2300 | 5 | 5 | 1000 | 500 | 1.5 |
| 10 | 2RL1600L-8 | 插件,8.0*8.0mm | 1600±20% | 2300 | 5 | 5 | 1000 | 500 | 1.5 |
| 11 | 2RL2000L-8 | 插件,8.0*8.0mm | 2000±20% | 3000 | 5 | 5 | 1000 | 500 | 1.5 |
| 12 | 2RL2500L-8 | 插件,8.0*8.0mm | 2500±20% | 3600 | 5 | 5 | 1000 | 500 | 1.5 |
